Cadena de valor: Logística, SCM y sistemas ERP

La cadena de valor es el concepto central para analizar y optimizar procesos empresariales. Comprende todas las actividades desde la adquisición de materias primas hasta la entrega al cliente final.

Fundamentos de la cadena de valor

Definición y concepto

La cadena de valor según Porter describe las actividades secuenciales que realiza una empresa para crear productos o servicios y entregarlos al cliente.

Actividades primarias

graph TD
    A[Logística de entrada] --> B[Operaciones]
    B --> C[Logística de salida]
    C --> D[Marketing y ventas]
    D --> E[Servicio]

    F[Actividades de apoyo] --> A
    F --> B
    F --> C
    F --> D
    F --> E

Actividades secundarias

• Infraestructura empresarial: Gestión, planificación, finanzas
• Gestión del personal: Reclutamiento, formación, compensación
• Desarrollo tecnológico: Investigación, mejora de procesos
• Compras: Adquisición de materias primas y servicios

Supply Chain Management (SCM)

Componentes del SCM

// Arquitectura del sistema SCM
public class SupplyChainManagement {

    // Gestión de compras
    public class ProcurementManagement {
        private List<Supplier> suppliers;
        private List<PurchaseOrder> orders;

        public void createPurchaseOrder(Product product, int quantity, Supplier supplier) {
            PurchaseOrder order = new PurchaseOrder(product, quantity, supplier);
            orders.add(order);

            // Evaluación de proveedores
            updateSupplierRating(supplier, calculateDeliveryPerformance(supplier));

            // Gestión de inventario
            updateInventory(product, quantity);
        }

        private void updateSupplierRating(Supplier supplier, double performance) {
            double currentRating = supplier.getPerformanceRating();
            double newRating = (currentRating + performance) / 2;
            supplier.setPerformanceRating(newRating);
        }
    }

    // Gestión de almacenes
    public class InventoryManagement {
        private Map<Product, Integer> stockLevels = new HashMap<>();
        private Map<Product, Integer> reorderPoints = new HashMap<>();

        public void checkReorderLevels() {
            for (Map.Entry<Product, Integer> entry : stockLevels.entrySet()) {
                Product product = entry.getKey();
                int currentStock = entry.getValue();
                int reorderPoint = reorderPoints.getOrDefault(product, 0);

                if (currentStock <= reorderPoint) {
                    triggerReorder(product, calculateOptimalOrderQuantity(product));
                }
            }
        }

        private int calculateOptimalOrderQuantity(Product product) {
            // Fórmula EOQ: sqrt(2 * D * S / H)
            double demand = product.getAnnualDemand();
            double setupCost = product.getSetupCost();
            double holdingCost = product.getHoldingCostPerUnit();

            return (int) Math.sqrt((2 * demand * setupCost) / holdingCost);
        }
    }

    // Gestión de transporte
    public class TransportationManagement {
        private List<Vehicle> vehicles;
        private List<Route> routes;

        public Route optimizeRoute(List<Delivery> deliveries) {
            // Aproximación del Problema del Viajante
            List<Location> locations = deliveries.stream()
                .map(Delivery::getLocation)
                .collect(Collectors.toList());

            return calculateOptimalRoute(locations);
        }

        private Route calculateOptimalRoute(List<Location> locations) {
            // Algoritmo del Vecino Más Cercano
            Route route = new Route();
            Location current = locations.get(0); // Inicio desde almacén

            while (!locations.isEmpty()) {
                Location nearest = findNearestLocation(current, locations);
                route.addLocation(nearest);
                locations.remove(nearest);
                current = nearest;
            }

            return route;
        }
    }
}

Componentes de software del SCM

-- Modelo de base de datos SCM
CREATE TABLE Suppliers (
    supplier_id INT PRIMARY KEY,
    name VARCHAR(100) NOT NULL,
    contact_person VARCHAR(100),
    email VARCHAR(100),
    phone VARCHAR(20),
    performance_rating DECIMAL(3,2),
    delivery_time INT,
    quality_score DECIMAL(3,2)
);

CREATE TABLE Products (
    product_id INT PRIMARY KEY,
    name VARCHAR(100) NOT NULL,
    description TEXT,
    unit_price DECIMAL(10,2),
    annual_demand INT,
    setup_cost DECIMAL(10,2),
    holding_cost_per_unit DECIMAL(10,2),
    reorder_point INT,
    current_stock INT
);

CREATE TABLE PurchaseOrders (
    order_id INT PRIMARY KEY,
    supplier_id INT,
    product_id INT,
    quantity INT,
    order_date DATE,
    expected_delivery_date DATE,
    actual_delivery_date DATE,
    status VARCHAR(20),
    unit_price DECIMAL(10,2),
    total_amount DECIMAL(12,2),
    FOREIGN KEY (supplier_id) REFERENCES Suppliers(supplier_id),
    FOREIGN KEY (product_id) REFERENCES Products(product_id)
);

CREATE TABLE InventoryTransactions (
    transaction_id INT PRIMARY KEY,
    product_id INT,
    transaction_type VARCHAR(20), -- 'IN', 'OUT', 'ADJUSTMENT'
    quantity INT,
    transaction_date TIMESTAMP DEFAULT CURRENT_TIMESTAMP,
    reference_id INT, -- Purchase Order ID or Sales Order ID
    notes TEXT,
    FOREIGN KEY (product_id) REFERENCES Products(product_id)
);

CREATE TABLE Shipments (
    shipment_id INT PRIMARY KEY,
    order_id INT,
    carrier VARCHAR(100),
    tracking_number VARCHAR(50),
    ship_date DATE,
    expected_delivery_date DATE,
    actual_delivery_date DATE,
    status VARCHAR(20),
    cost DECIMAL(10,2)
);

Gestión de logística

Logística de transporte y almacenamiento

# Ejemplo en Python para optimización logística
import numpy as np
from scipy.optimize import linear_sum_assignment
from datetime import datetime, timedelta

class LogisticsOptimizer:

    def __init__(self):
        self.warehouses = []
        self.customers = []
        self.vehicles = []

    def optimize_distribution(self, demand_matrix, cost_matrix):
        """
        Optimiza la distribución de mercancías entre almacenes
        Utiliza el algoritmo húngaro para problemas de asignación
        """
        # Algoritmo húngaro para costes mínimos
        row_ind, col_ind = linear_sum_assignment(cost_matrix)

        optimal_assignment = []
        total_cost = 0

        for i, j in zip(row_ind, col_ind):
            if demand_matrix[i, j] > 0:
                optimal_assignment.append({
                    'warehouse': i,
                    'customer': j,
                    'quantity': demand_matrix[i, j],
                    'cost': cost_matrix[i, j]
                })
                total_cost += demand_matrix[i, j] * cost_matrix[i, j]

        return optimal_assignment, total_cost

    def calculate_transport_costs(self, distance, weight, transport_mode):
        """
        Calcula costes de transporte según diversos factores
        """
        base_rates = {
            'truck': 0.15,      # € por km por 100kg
            'rail': 0.08,       # € por km por 100kg
            'air': 0.45,        # € por km por 100kg
            'ship': 0.05        # € por km por 100kg
        }

        base_rate = base_rates.get(transport_mode, 0.15)
        cost = distance * (weight / 100) * base_rate

        # Costes adicionales
        if transport_mode == 'air':
            cost += 50  # Tarifa de manipulación
        elif transport_mode == 'ship':
            cost += 25  # Tarifa portuaria

        return cost

    def optimize_vehicle_loading(self, packages, vehicle_capacity):
        """
        Problema de empaquetamiento para carga óptima de vehículos
        """
        # Algoritmo codicioso para empaquetamiento
        packages_sorted = sorted(packages, key=lambda x: x['weight'], reverse=True)
        vehicles = []

        for package in packages_sorted:
            placed = False

            # Intenta colocar el paquete en un vehículo existente
            for vehicle in vehicles:
                if vehicle['used_capacity'] + package['weight'] <= vehicle_capacity:
                    vehicle['packages'].append(package)
                    vehicle['used_capacity'] += package['weight']
                    placed = True
                    break

            # Crea un vehículo nuevo si no hay espacio
            if not placed:
                vehicles.append({
                    'packages': [package],
                    'used_capacity': package['weight'],
                    'capacity': vehicle_capacity
                })

        return vehicles

# Ejemplo de optimización logística
optimizer = LogisticsOptimizer()

# Matriz de demanda (almacenes x clientes)
demand_matrix = np.array([
    [100, 150, 200, 0, 50],   # Almacén 1
    [0, 200, 100, 150, 100],  # Almacén 2
    [150, 0, 100, 200, 150]   # Almacén 3
])

# Matriz de costes (€ por unidad)
cost_matrix = np.array([
    [10, 15, 20, 25, 30],     # Desde almacén 1
    [20, 10, 15, 20, 25],     # Desde almacén 2
    [15, 20, 10, 15, 20]      # Desde almacén 3
])

assignment, total_cost = optimizer.optimize_distribution(demand_matrix, cost_matrix)
print(f"Coste total óptimo: €{total_cost:.2f}")

Planificación de rutas

// JavaScript para planificación de rutas con Google Maps API
class RouteOptimizer {
    constructor() {
        this.apiKey = 'YOUR_GOOGLE_MAPS_API_KEY';
    }

    async calculateOptimalRoute(locations, vehicleConstraints) {
        // Vehicle Routing Problem con Google Directions API
        const waypoints = locations.slice(1, -1).map(loc => ({
            location: loc.address,
            stopover: true
        }));

        const request = {
            origin: locations[0].address,
            destination: locations[locations.length - 1].address,
            waypoints: waypoints,
            optimize: true, // Optimiza el orden
            travelMode: 'DRIVING',
            unitSystem: 'METRIC',
            vehicleConstraints: vehicleConstraints
        };

        try {
            const response = await this.callDirectionsAPI(request);
            return this.processRouteResponse(response);
        } catch (error) {
            console.error('Cálculo de ruta fallido:', error);
            return null;
        }
    }

    async callDirectionsAPI(request) {
        const url = `https://routes.googleapis.com/directions/v2:computeRoutes?key=${this.apiKey}`;

        const response = await fetch(url, {
            method: 'POST',
            headers: {
                'Content-Type': 'application/json',
                'X-Goog-Api-Key': this.apiKey
            },
            body: JSON.stringify(request)
        });

        return response.json();
    }

    processRouteResponse(response) {
        const optimizedRoute = {
            totalDistance: response.routes[0].legs.reduce((sum, leg) => sum + leg.distance.value, 0),
            totalDuration: response.routes[0].legs.reduce((sum, leg) => sum + leg.duration.value, 0),
            waypoints: response.routes[0].waypoint_order,
            legs: response.routes[0].legs.map(leg => ({
                distance: leg.distance,
                duration: leg.duration,
                start_address: leg.start_address,
                end_address: leg.end_address,
                steps: leg.steps
            }))
        };

        return optimizedRoute;
    }

    calculateFuelConsumption(distance, vehicleType) {
        const fuelConsumptionRates = {
            'small_truck': 0.12,    // Litros por km
            'medium_truck': 0.18,
            'large_truck': 0.25,
            'van': 0.08
        };

        const rate = fuelConsumptionRates[vehicleType] || 0.15;
        return distance * rate;
    }

    estimateDeliveryTime(distance, trafficConditions) {
        const baseSpeed = 80; // km/h
        const trafficFactor = trafficConditions === 'heavy' ? 0.6 :
                           trafficConditions === 'moderate' ? 0.8 : 1.0;

        const adjustedSpeed = baseSpeed * trafficFactor;
        return distance / adjustedSpeed; // Horas
    }
}

// Ejemplo de optimización de rutas
const optimizer = new RouteOptimizer();

const locations = [
    { address: 'Múnich, Alemania', type: 'warehouse' },
    { address: 'Augsburgo, Alemania', type: 'customer' },
    { address: 'Ingolstadt, Alemania', type: 'customer' },
    { address: 'Núremberg, Alemania', type: 'customer' },
    { address: 'Ratisbona, Alemania', type: 'warehouse' }
];

const vehicleConstraints = {
    maxWeight: 3500, // kg
    maxHeight: 3.0,  // metros
    hazardousMaterials: false
};

optimizer.calculateOptimalRoute(locations, vehicleConstraints)
    .then(route => {
        console.log('Ruta optimizada:', route);
    });

Sistemas ERP en la cadena de valor

Arquitectura de módulos ERP

-- Modelo de base de datos ERP para la cadena de valor
CREATE TABLE Companies (
    company_id INT PRIMARY KEY,
    name VARCHAR(100) NOT NULL,
    tax_id VARCHAR(50),
    address VARCHAR(200),
    phone VARCHAR(50),
    email VARCHAR(100),
    website VARCHAR(100)
);

CREATE TABLE Warehouses (
    warehouse_id INT PRIMARY KEY,
    company_id INT,
    name VARCHAR(100),
    address VARCHAR(200),
    capacity DECIMAL(10,2),
    manager_id INT,
    FOREIGN KEY (company_id) REFERENCES Companies(company_id)
);

CREATE TABLE ProductionOrders (
    production_order_id INT PRIMARY KEY,
    product_id INT,
    quantity INT,
    start_date DATE,
    end_date DATE,
    status VARCHAR(20),
    priority INT,
    assigned_workcenter_id INT,
    material_cost DECIMAL(12,2),
    labor_cost DECIMAL(12,2),
    overhead_cost DECIMAL(12,2)
);

CREATE TABLE WorkCenters (
    workcenter_id INT PRIMARY KEY,
    name VARCHAR(100),
    capacity_per_hour DECIMAL(8,2),
    setup_time_minutes INT,
    efficiency_rate DECIMAL(3,2),
    maintenance_cost_per_hour DECIMAL(8,2)
);

CREATE TABLE QualityChecks (
    check_id INT PRIMARY KEY,
    production_order_id INT,
    check_date TIMESTAMP,
    inspector_id INT,
    result VARCHAR(20), -- 'PASS', 'FAIL', 'REWORK'
    defects_found INT,
    corrective_action TEXT,
    FOREIGN KEY (production_order_id) REFERENCES ProductionOrders(production_order_id)
);

Funcionalidad similar a SAP

// Sistema ERP con funcionalidad similar a SAP
public class ERPSystem {

    // Material Management (MM)
    public class MaterialManagement {
        private Map<String, Material> materials = new HashMap<>();
        private Map<String, MaterialDocument> materialDocuments = new HashMap<>();

        public void createMaterial(String materialNumber, String description,
                                String materialType, String unitOfMeasure) {
            Material material = new Material(materialNumber, description,
                                           materialType, unitOfMeasure);
            materials.put(materialNumber, material);
        }

        public MaterialDocument postGoodsMovement(String materialNumber, int quantity,
                                                String movementType, String storageLocation) {
            Material material = materials.get(materialNumber);
            if (material == null) {
                throw new IllegalArgumentException("Material not found: " + materialNumber);
            }

            // Actualizar existencias
            updateStockLevels(materialNumber, quantity, movementType, storageLocation);

            // Crear documento de material
            MaterialDocument document = new MaterialDocument(
                generateDocumentNumber(), materialNumber, quantity,
                movementType, storageLocation, new Date()
            );

            materialDocuments.put(document.getDocumentNumber(), document);
            return document;
        }

        private void updateStockLevels(String materialNumber, int quantity,
                                     String movementType, String storageLocation) {
            // Actualizar inventario según el tipo de movimiento
            switch (movementType) {
                case "101": // Recepción de mercancía
                    increaseStock(materialNumber, quantity, storageLocation);
                    break;
                case "201": // Salida de almacén
                    decreaseStock(materialNumber, quantity, storageLocation);
                    break;
                case "301": // Transferencia de almacén
                    transferStock(materialNumber, quantity, storageLocation);
                    break;
            }
        }
    }

    // Sales and Distribution (SD)
    public class SalesDistribution {
        private Map<String, SalesOrder> salesOrders = new HashMap<>();
        private Map<String, Customer> customers = new HashMap<>();
        private Map<String, BillingDocument> billingDocuments = new HashMap<>();

        public SalesOrder createSalesOrder(String customerNumber, List<OrderItem> items) {
            Customer customer = customers.get(customerNumber);
            if (customer == null) {
                throw new IllegalArgumentException("Customer not found: " + customerNumber);
            }

            // Cálculo de precios
            BigDecimal totalAmount = calculateTotalAmount(items, customer);

            // Verificar disponibilidad
            checkAvailability(items);

            SalesOrder salesOrder = new SalesOrder(
                generateOrderNumber(), customerNumber, items,
                new Date(), "OPEN", totalAmount
            );

            salesOrders.put(salesOrder.getOrderNumber(), salesOrder);
            return salesOrder;
        }

        public BillingDocument createBillingDocument(String salesOrderNumber) {
            SalesOrder salesOrder = salesOrders.get(salesOrderNumber);
            if (salesOrder == null) {
                throw new IllegalArgumentException("Sales order not found: " + salesOrderNumber);
            }

            BillingDocument billingDocument = new BillingDocument(
                generateBillingNumber(), salesOrderNumber,
                salesOrder.getItems(), salesOrder.getTotalAmount(), new Date()
            );

            billingDocuments.put(billingDocument.getBillingNumber(), billingDocument);
            return billingDocument;
        }

        private BigDecimal calculateTotalAmount(List<OrderItem> items, Customer customer) {
            BigDecimal total = BigDecimal.ZERO;

            for (OrderItem item : items) {
                // Considerar precios específicos del cliente
                BigDecimal unitPrice = getCustomerSpecificPrice(item.getMaterialNumber(), customer);
                BigDecimal itemTotal = unitPrice.multiply(BigDecimal.valueOf(item.getQuantity()));
                total = total.add(itemTotal);
            }

            // Aplicar descuentos y recargos
            total = applyDiscountsAndSurcharges(total, customer);

            return total;
        }
    }

    // Production Planning (PP)
    public class ProductionPlanning {
        private Map<String, ProductionOrder> productionOrders = new HashMap<>();
        private Map<String, WorkCenter> workCenters = new HashMap<>();

        public ProductionOrder createProductionOrder(String materialNumber, int quantity,
                                                   Date requiredDate) {
            // Planificación de capacidad
            WorkCenter suitableWorkCenter = findSuitableWorkCenter(materialNumber);

            // Planificación de plazos
            Date startDate = calculateStartDate(requiredDate, quantity, suitableWorkCenter);
            Date endDate = calculateEndDate(startDate, quantity, suitableWorkCenter);

            // Planificación de necesidades de material
            List<MaterialRequirement> requirements =
                calculateMaterialRequirements(materialNumber, quantity);

            ProductionOrder order = new ProductionOrder(
                generateProductionOrderNumber(), materialNumber, quantity,
                startDate, endDate, suitableWorkCenter.getId(), "CREATED",
                requirements
            );

            productionOrders.add(order);
            return order;
        }

        private List<MaterialRequirement> calculateMaterialRequirements(String materialNumber,
                                                                      int quantity) {
            List<MaterialRequirement> requirements = new ArrayList<>();

            // Expandir lista de materiales
            BillOfMaterials bom = getBillOfMaterials(materialNumber);

            for (BOMItem bomItem : bom.getItems()) {
                double requiredQuantity = bomItem.getQuantity() * quantity;

                MaterialRequirement requirement = new MaterialRequirement(
                    bomItem.getMaterialNumber(), requiredQuantity,
                    bomItem.getUnitOfMeasure(), "OPEN"
                );

                requirements.add(requirement);
            }

            return requirements;
        }
    }
}

Optimización de Procesos

Principios de Lean Management

# Implementación de Lean Management
class LeanManagement:

    def __init__(self):
        self.waste_types = [
            'overproduction', 'waiting', 'transportation',
            'inventory', 'motion', 'overprocessing', 'defects'
        ]
        self.value_stream_maps = {}

    def analyze_waste(self, process_data):
        """
        Análisis de los 7 tipos de desperdicio (Muda)
        """
        waste_analysis = {}

        for waste_type in self.waste_types:
            waste_analysis[waste_type] = self.calculate_waste_metrics(
                process_data, waste_type
            )

        return waste_analysis

    def calculate_waste_metrics(self, process_data, waste_type):
        """
        Calcula métricas específicas para cada tipo de desperdicio
        """
        metrics = {}

        if waste_type == 'waiting':
            # Analizar tiempos de espera
            waiting_times = []
            for step in process_data['process_steps']:
                waiting_times.append(step.get('waiting_time', 0))

            metrics['total_waiting_time'] = sum(waiting_times)
            metrics['average_waiting_time'] = sum(waiting_times) / len(waiting_times)
            metrics['waiting_percentage'] = (metrics['total_waiting_time'] /
                                           process_data['total_cycle_time']) * 100

        elif waste_type == 'inventory':
            # Analizar sobrecarga de inventario
            current_inventory = process_data.get('current_inventory', 0)
            optimal_inventory = process_data.get('optimal_inventory', 0)

            excess_inventory = max(0, current_inventory - optimal_inventory)
            metrics['excess_inventory'] = excess_inventory
            metrics['excess_inventory_value'] = excess_inventory * process_data.get('unit_cost', 0)

        elif waste_type == 'defects':
            # Analizar tasa de defectos
            total_units = process_data.get('total_units', 0)
            defective_units = process_data.get('defective_units', 0)

            metrics['defect_rate'] = (defective_units / total_units) * 100
            metrics['rework_cost'] = defective_units * process_data.get('rework_cost_per_unit', 0)

        return metrics

    def implement_5s(self, workplace_data):
        """
        Implementar la metodología 5S
        """
        improvements = []

        # 1S - Seiri (Ordenar)
        improvements.append(self.implement_sorting(workplace_data))

        # 2S - Seiton (Organizar)
        improvements.append(self.implement_systematization(workplace_data))

        # 3S - Seiso (Limpiar)
        improvements.append(self.implement_cleaning(workplace_data))

        # 4S - Seiketsu (Estandarizar)
        improvements.append(self.implement_standardization(workplace_data))

        # 5S - Shitsuke (Disciplina)
        improvements.append(self.implement_discipline(workplace_data))

        return improvements

    def implement_kaizen(self, current_process):
        """
        Mejora continua (Kaizen)
        """
        kaizen_suggestions = []

        # Analizar pasos del proceso
        for i, step in enumerate(current_process['steps']):
            # Identificar cuellos de botella
            if step.get('cycle_time', 0) > current_process.get('target_cycle_time', 0):
                kaizen_suggestions.append({
                    'step': i,
                    'issue': 'Cycle time exceeds target',
                    'suggestion': 'Optimize work sequence or reduce setup time',
                    'potential_improvement': step['cycle_time'] - current_process['target_cycle_time']
                })

            # Identificar problemas de calidad
            if step.get('defect_rate', 0) > current_process.get('target_defect_rate', 0):
                kaizen_suggestions.append({
                    'step': i,
                    'issue': 'Defect rate exceeds target',
                    'suggestion': 'Implement error-proofing or improve training',
                    'potential_improvement': step['defect_rate'] - current_process['target_defect_rate']
                })

        return kaizen_suggestions

Implementación de Six Sigma

// Metodología Six Sigma DMAIC
public class SixSigmaImplementation {

    // Fase Define
    public ProjectDefinition defineProject(String problemStatement,
                                         List<String> stakeholders,
                                         Map<String, Object> projectGoals) {
        ProjectDefinition definition = new ProjectDefinition();
        definition.setProblemStatement(problemStatement);
        definition.setStakeholders(stakeholders);
        definition.setProjectGoals(projectGoals);

        // Definir CTQs (Critical to Quality)
        List<CriticalToQuality> ctqs = identifyCriticalToQuality(problemStatement);
        definition.setCriticalToQualities(ctqs);

        return definition;
    }

    // Fase Measure
    public MeasurementSystem measureCurrentState(ProcessData currentData) {
        MeasurementSystem measurement = new MeasurementSystem();

        // Analizar capacidad del proceso (Cpk, Ppk)
        double cpk = calculateProcessCapabilityIndex(currentData);
        double ppk = calculateProcessPerformanceIndex(currentData);

        measurement.setCpk(cpk);
        measurement.setPpk(ppk);

        // Análisis del sistema de medición (MSA)
        MeasurementSystemAnalysis msa = performMeasurementSystemAnalysis(currentData);
        measurement.setMsaResults(msa);

        return measurement;
    }

    // Fase Analyze
    public AnalysisResults analyzeRootCauses(ProcessData data, List<String> potentialCauses) {
        AnalysisResults results = new AnalysisResults();

        // Análisis estadístico
        for (String cause : potentialCauses) {
            double correlation = calculateCorrelation(data, cause);
            double significance = calculateSignificance(data, cause);

            if (significance < 0.05) { // Nivel de significancia 5%
                results.addSignificantCause(cause, correlation, significance);
            }
        }

        // Análisis de causa raíz
        List<String> rootCauses = performRootCauseAnalysis(results.getSignificantCauses());
        results.setRootCauses(rootCauses);

        return results;
    }

    // Fase Improve
    public ImprovementPlan developImprovementPlan(List<String> rootCauses) {
        ImprovementPlan plan = new ImprovementPlan();

        for (String cause : rootCauses) {
            List<String> solutions = generateSolutions(cause);

            for (String solution : solutions) {
                SolutionEvaluation evaluation = evaluateSolution(solution, cause);

                if (evaluation.getExpectedBenefit() > evaluation.getImplementationCost()) {
                    plan.addSolution(solution, evaluation);
                }
            }
        }

        // Priorizar soluciones
        plan.prioritizeSolutions();

        return plan;
    }

    // Fase Control
    public ControlSystem implementControlSystem(ImprovementPlan plan) {
        ControlSystem control = new ControlSystem();

        // Implementar cartas de control
        for (Solution solution : plan.getSelectedSolutions()) {
            ControlChart chart = createControlChart(solution);
            control.addControlChart(chart);
        }

        // Configurar sistema de alerta temprana
        EarlyWarningSystem warningSystem = setupEarlyWarningSystem(control);
        control.setEarlyWarningSystem(warningSystem);

        return control;
    }

    private double calculateProcessCapabilityIndex(ProcessData data) {
        double mean = data.getMean();
        double stdDev = data.getStandardDeviation();
        double upperSpec = data.getUpperSpecificationLimit();
        double lowerSpec = data.getLowerSpecificationLimit();

        double cpu = (upperSpec - mean) / (3 * stdDev);
        double cpl = (mean - lowerSpec) / (3 * stdDev);

        return Math.min(cpu, cpl);
    }

    private ControlChart createControlChart(Solution solution) {
        ControlChart chart = new ControlChart();
        chart.setProcessParameter(solution.getMonitoredParameter());
        chart.setUpperControlLimit(solution.getUpperControlLimit());
        chart.setLowerControlLimit(solution.getLowerControlLimit());
        chart.setCenterLine(solution.getTargetValue());

        return chart;
    }
}

Transformación digital en la cadena de valor

Integración Industry 4.0

# IoT y Mantenimiento Predictivo
class Industry40Integration:

    def __init__(self):
        self.sensors = {}
        self.predictive_models = {}

    def setup_iot_sensors(self, equipment_id, sensor_types):
        """
        Configurar sensores IoT para equipos de producción
        """
        sensors = {}

        for sensor_type in sensor_types:
            sensor = {
                'type': sensor_type,
                'equipment_id': equipment_id,
                'data_points': [],
                'thresholds': self.get_sensor_thresholds(sensor_type),
                'last_maintenance': datetime.now()
            }
            sensors[sensor_type] = sensor

        self.sensors[equipment_id] = sensors
        return sensors

    def predict_maintenance_needs(self, equipment_id):
        """
        Predecir necesidades de mantenimiento con Machine Learning
        """
        if equipment_id not in self.sensors:
            return None

        sensors = self.sensors[equipment_id]
        maintenance_prediction = {
            'equipment_id': equipment_id,
            'prediction_date': datetime.now(),
            'maintenance_needed': False,
            'urgency': 'LOW',
            'predicted_failure_date': None,
            'recommendations': []
        }

        # Analizar datos de sensores
        for sensor_type, sensor_data in sensors.items():
            recent_data = sensor_data['data_points'][-100:]  # Últimos 100 puntos de datos

            if len(recent_data) > 50:
                # Análisis de tendencias
                trend = self.calculate_trend(recent_data)

                # Detección de anomalías
                anomalies = self.detect_anomalies(recent_data, sensor_data['thresholds'])

                # Aplicar modelo de predicción
                failure_probability = self.predict_failure_probability(
                    recent_data, sensor_type
                )

                if failure_probability > 0.7:  # Alta probabilidad de fallo
                    maintenance_prediction['maintenance_needed'] = True
                    maintenance_prediction['urgency'] = 'HIGH'
                    maintenance_prediction['predicted_failure_date'] = \
                        self.predict_failure_date(recent_data, failure_probability)

                    maintenance_prediction['recommendations'].append(
                        f"Immediate inspection required for {sensor_type} sensor"
                    )
                elif failure_probability > 0.4:  # Probabilidad media de fallo
                    maintenance_prediction['urgency'] = 'MEDIUM'
                    maintenance_prediction['recommendations'].append(
                        f"Schedule maintenance for {sensor_type} within 2 weeks"
                    )

        return maintenance_prediction

    def optimize_production_schedule(self, production_orders, equipment_status):
        """
        Optimizar la planificación de producción con estado en tiempo real
        """
        optimized_schedule = []
        available_equipment = [eq for eq in equipment_status if eq['status'] == 'AVAILABLE']

        for order in production_orders:
            # Encontrar equipos adecuados
            suitable_equipment = self.find_suitable_equipment(
                order, available_equipment
            )

            if suitable_equipment:
                # Pronosticar tiempo de producción
                estimated_time = self.estimate_production_time(
                    order, suitable_equipment
                )

                # Optimizar consumo de energía
                energy_optimization = self.optimize_energy_consumption(
                    order, suitable_equipment
                )

                scheduled_order = {
                    'order_id': order['id'],
                    'equipment_id': suitable_equipment['id'],
                    'start_time': self.calculate_start_time(order, optimized_schedule),
                    'estimated_duration': estimated_time,
                    'energy_optimization': energy_optimization
                }

                optimized_schedule.append(scheduled_order)

                # Marcar equipo como ocupado
                suitable_equipment['status'] = 'BUSY'

        return optimized_schedule

    def implement_blockchain_supply_chain(self):
        """
        Implementar Blockchain para cadenas de suministro transparentes
        """
        blockchain = SupplyChainBlockchain()

        # Smart Contracts para eventos de cadena de suministro
        blockchain.deploy_smart_contract('ProductTracking', '''
            contract ProductTracking {
                struct Product {
                    uint256 id;
                    string currentLocation;
                    uint256 timestamp;
                    address currentHolder;
                    string status;
                }

                mapping(uint256 => Product) public products;

                event ProductMoved(uint256 productId, string newLocation, address newHolder);

                function moveProduct(uint256 productId, string memory newLocation, address newHolder) public {
                    products[productId].currentLocation = newLocation;
                    products[productId].currentHolder = newHolder;
                    products[productId].timestamp = block.timestamp;

                    emit ProductMoved(productId, newLocation, newHolder);
                }
            }
        ''')

        return blockchain

KPIs y medición de desempeño

Indicadores clave

-- Panel de control KPI para cadena de valor
CREATE TABLE SupplyChainKPIs (
    kpi_id INT PRIMARY KEY,
    kpi_name VARCHAR(100) NOT NULL,
    kpi_category VARCHAR(50), -- 'Efficiency', 'Quality', 'Cost', 'Delivery'
    calculation_method TEXT,
    target_value DECIMAL(10,2),
    current_value DECIMAL(10,2),
    measurement_date DATE,
    trend VARCHAR(10) -- 'IMPROVING', 'DECLINING', 'STABLE'
);

-- Cálculos de KPI
CREATE VIEW SupplyChainPerformance AS
SELECT
    -- Eficiencia de la cadena de suministro
    (SELECT COUNT(*) FROM PurchaseOrders WHERE status = 'DELIVERED' AND
     DATEDIFF(actual_delivery_date, expected_delivery_date) <= 0) * 100.0 /
    (SELECT COUNT(*) FROM PurchaseOrders WHERE status = 'DELIVERED') AS on_time_delivery_rate,

    -- Eficiencia de inventario
    (SELECT SUM(current_stock * unit_cost) FROM Products) /
    (SELECT SUM(annual_demand * unit_cost) FROM Products) * 100 AS inventory_turnover_ratio,

    -- Calidad
    (SELECT COUNT(*) FROM QualityChecks WHERE result = 'PASS') * 100.0 /
    (SELECT COUNT(*) FROM QualityChecks) AS first_pass_yield,

    -- Costos
    (SELECT SUM(total_amount) FROM PurchaseOrders WHERE
     DATE(order_date) >= DATE_SUB(CURRENT_DATE, INTERVAL 30 DAY)) /
    (SELECT SUM(quantity) FROM InventoryTransactions WHERE
     transaction_type = 'IN' AND
     DATE(transaction_date) >= DATE_SUB(CURRENT_DATE, INTERVAL 30 DAY))
    AS average_cost_per_unit;

Monitoreo de rendimiento

# Real-time Performance Monitoring
class SupplyChainMonitor:

    def __init__(self):
        self.kpi_thresholds = {
            'on_time_delivery_rate': 95.0,
            'inventory_turnover_ratio': 12.0,
            'first_pass_yield': 98.0,
            'order_fulfillment_cycle_time': 24.0
        }
        self.alerts = []

    def monitor_real_time_kpis(self):
        """
        Supervisión en tiempo real de los KPIs principales
        """
        current_kpis = self.calculate_current_kpis()
        alerts = []

        for kpi_name, threshold in self.kpi_thresholds.items():
            current_value = current_kpis.get(kpi_name, 0)

            if current_value < threshold:
                alert = {
                    'kpi_name': kpi_name,
                    'current_value': current_value,
                    'threshold': threshold,
                    'severity': self.calculate_alert_severity(current_value, threshold),
                    'timestamp': datetime.now(),
                    'recommendations': self.generate_recommendations(kpi_name, current_value)
                }
                alerts.append(alert)

        self.alerts.extend(alerts)
        return alerts

    def calculate_current_kpis(self):
        """
        Calcula los valores de KPI actuales desde la base de datos
        """
        kpis = {}

        # On-Time Delivery Rate
        delivered_orders = self.get_delivered_orders_count()
        total_orders = self.get_total_orders_count()
        kpis['on_time_delivery_rate'] = (delivered_orders / total_orders) * 100 if total_orders > 0 else 0

        # Inventory Turnover Ratio
        total_inventory_value = self.get_total_inventory_value()
        annual_cost_of_goods_sold = self.get_annual_cogs()
        kpis['inventory_turnover_ratio'] = annual_cost_of_goods_sold / total_inventory_value if total_inventory_value > 0 else 0

        # First Pass Yield
        passed_inspections = self.get_passed_inspections_count()
        total_inspections = self.get_total_inspections_count()
        kpis['first_pass_yield'] = (passed_inspections / total_inspections) * 100 if total_inspections > 0 else 0

        # Order Fulfillment Cycle Time
        order_cycles = self.get_order_cycle_times()
        kpis['order_fulfillment_cycle_time'] = sum(order_cycles) / len(order_cycles) if order_cycles else 0

        return kpis

    def generate_dashboard_data(self):
        """
        Datos del dashboard para la vista general de la gerencia
        """
        kpis = self.calculate_current_kpis()
        alerts = self.monitor_real_time_kpis()

        dashboard_data = {
            'current_kpis': kpis,
            'active_alerts': alerts,
            'trend_analysis': self.analyze_trends(),
            'benchmark_comparison': self.compare_with_benchmarks(kpis),
            'improvement_opportunities': self.identify_improvement_opportunities(kpis)
        }

        return dashboard_data

Conceptos relevantes para el examen

Términos importantes

Término	Descripción	Significado
Cadena de valor	Secuencia de actividades para crear valor	Modelo de Porter
SCM	Gestión de procesos de la cadena de suministro	Integración y optimización
ERP	Enterprise Resource Planning	Procesos empresariales integrados
Lean Management	Eliminar desperdicios	5S, Kaizen, Just-in-Time
Six Sigma	Mejora de calidad	DMAIC, Control estadístico de procesos

Tareas típicas de examen

1. Analizar cadenas de valor
2. Optimizar procesos de la cadena de suministro
3. Implementar módulos ERP
4. Aplicar Lean Management
5. Calcular KPIs de la cadena de suministro

Resumen

Las cadenas de valor modernas requieren enfoques integrados:

• Los sistemas SCM optimizan los procesos de la cadena de suministro
• La integración ERP crea procesos continuos
• Lean y Six Sigma eliminan desperdicios
• La digitalización permite optimización en tiempo real
• El monitoreo de KPIs garantiza mejora continua

Las cadenas de valor exitosas están impulsadas por datos, orientadas al cliente y continuamente optimizadas.
