REST API Fundamentals: HTTP Methods, Status Codes & HATEOAS

This article is a comprehensive explanation of REST API fundamentals – including HTTP methods, status codes, and HATEOAS principles.

In a Nutshell

REST is an architectural style for distributed systems that uses HTTP methods, status codes, and HATEOAS to create scalable and stateless web services.

Compact Technical Description

Representational State Transfer (REST) is an architectural style for web services defined by Roy Fielding. REST uses the semantics of HTTP for operations on resources.

Core Principles:

Client-Server: Separation of responsibilities
Stateless: No session states on server side
Cacheable: Responses can be cached
Uniform Interface: Uniform interface via HTTP
Layered System: Intermediate layers possible
Code on Demand: Optional: Server can send code to client

HTTP Methods:

GET: Read resource (safe, idempotent)
POST: Create resource (not safe, not idempotent)
PUT: Replace resource (not safe, idempotent)
PATCH: Partially modify resource (not safe, not idempotent)
DELETE: Delete resource (not safe, idempotent)

HATEOAS (Hypermedia as the Engine of Application State) enables navigation through APIs without hard-coded URLs.

Exam-Relevant Key Points

HTTP Methods: GET, POST, PUT, DELETE with correct semantics
Status Codes: 2xx (Success), 3xx (Redirect), 4xx (Client Error), 5xx (Server Error)
HATEOAS: Hypermedia as application control
Stateless: No session states on server side
Richardson Maturity Model: Maturity level model for REST APIs
Resource Naming: Consistent URI structure and nomenclature
IHK-relevant for web development and software architecture

Core Components

Resources: Unique identifiers (URIs) for data
HTTP Methods: CRUD operations via HTTP verbs
Status Codes: Standardized response codes
Representations: JSON, XML, HTML as data formats
Hypermedia: Links for navigation between resources
Statelessness: Every request contains all required information
Cacheability: Responses can be cached
Layered System: Load balancers, proxies, gateways

Practical Examples

1. Resource Design and HTTP Methods

// Express.js REST API example
const express = require('express');
const app = express();
app.use(express.json());

// Data (in-memory)
let users = [
  { id: 1, name: 'Alice', email: 'alice@example.com' },
  { id: 2, name: 'Bob', email: 'bob@example.com' }
];

// GET /users - Read all users
app.get('/users', (req, res) => {
  res.status(200).json({
    users: users,
    _links: {
      self: { href: '/users' },
      create: { href: '/users', method: 'POST' }
    }
  });
});

// GET /users/{id} - Read single user
app.get('/users/:id', (req, res) => {
  const user = users.find(u => u.id === parseInt(req.params.id));

  if (!user) {
    return res.status(404).json({
      error: 'User not found',
      _links: {
        users: { href: '/users' }
      }
    });
  }

  res.status(200).json({
    user: user,
    _links: {
      self: { href: `/users/${user.id}` },
      update: { href: `/users/${user.id}`, method: 'PUT' },
      delete: { href: `/users/${user.id}`, method: 'DELETE' },
      users: { href: '/users' }
    }
  });
});

// POST /users - Create new user
app.post('/users', (req, res) => {
  const { name, email } = req.body;

  if (!name || !email) {
    return res.status(400).json({
      error: 'Name and email are required',
      _links: {
        users: { href: '/users' }
      }
    });
  }

  const newUser = {
    id: users.length + 1,
    name,
    email
  };

  users.push(newUser);

  res.status(201).json({
    message: 'User created successfully',
    user: newUser,
    _links: {
      self: { href: `/users/${newUser.id}` },
      users: { href: '/users' }
    }
  });
});

// PUT /users/{id} - Completely replace user
app.put('/users/:id', (req, res) => {
  const { name, email } = req.body;
  const userId = parseInt(req.params.id);

  const userIndex = users.findIndex(u => u.id === userId);

  if (userIndex === -1) {
    return res.status(404).json({
      error: 'User not found',
      _links: {
        users: { href: '/users' }
      }
    });
  }

  if (!name || !email) {
    return res.status(400).json({
      error: 'Name and email are required',
      _links: {
        user: { href: `/users/${userId}` }
      }
    });
  }

  users[userIndex] = { id: userId, name, email };

  res.status(200).json({
    message: 'User updated successfully',
    user: users[userIndex],
    _links: {
      self: { href: `/users/${userId}` },
      users: { href: '/users' }
    }
  });
});

// DELETE /users/{id} - Delete user
app.delete('/users/:id', (req, res) => {
  const userId = parseInt(req.params.id);
  const userIndex = users.findIndex(u => u.id === userId);

  if (userIndex === -1) {
    return res.status(404).json({
      error: 'User not found',
      _links: {
        users: { href: '/users' }
      }
    });
  }

  users.splice(userIndex, 1);

  res.status(200).json({
    message: 'User deleted successfully',
    _links: {
      users: { href: '/users' },
      create: { href: '/users', method: 'POST' }
    }
  });
});

app.listen(3000, () => {
  console.log('REST API Server running on port 3000');
});

2. Spring Boot REST API with HATEOAS

@RestController
@RequestMapping("/api/products")
public class ProductController {

    @Autowired
    private ProductService productService;

    // GET /api/products - All products with HATEOAS
    @GetMapping
    public ResponseEntity<CollectionModel<EntityModel<Product>>> getAllProducts() {
        List<Product> products = productService.findAll();

        List<EntityModel<Product>> productModels = products.stream()
            .map(product -> EntityModel.of(product,
                linkTo(methodOn(ProductController.class).getProduct(product.getId())).withSelfRel(),
                linkTo(methodOn(ProductController.class).getAllProducts()).withRel("products")
            ))
            .collect(Collectors.toList());

        CollectionModel<EntityModel<Product>> collectionModel =
            CollectionModel.of(productModels,
                linkTo(methodOn(ProductController.class).getAllProducts()).withSelfRel()
            );

        return ResponseEntity.ok(collectionModel);
    }

    // GET /api/products/{id} - Single product with HATEOAS
    @GetMapping("/{id}")
    public ResponseEntity<EntityModel<Product>> getProduct(@PathVariable Long id) {
        return productService.findById(id)
            .map(product -> EntityModel.of(product,
                linkTo(methodOn(ProductController.class).getProduct(id)).withSelfRel(),
                linkTo(methodOn(ProductController.class).getAllProducts()).withRel("products"),
                linkTo(methodOn(ProductController.class).updateProduct(id, null)).withRel("update"),
                linkTo(methodOn(ProductController.class).deleteProduct(id)).withRel("delete")
            ))
            .map(ResponseEntity::ok)
            .orElse(ResponseEntity.notFound().build());
    }

    // POST /api/products - Create product
    @PostMapping
    public ResponseEntity<EntityModel<Product>> createProduct(@RequestBody Product product) {
        Product createdProduct = productService.save(product);

        EntityModel<Product> productModel = EntityModel.of(createdProduct,
            linkTo(methodOn(ProductController.class).getProduct(createdProduct.getId())).withSelfRel(),
            linkTo(methodOn(ProductController.class).getAllProducts()).withRel("products")
        );

        return ResponseEntity
            .created(URI.create("/api/products/" + createdProduct.getId()))
            .body(productModel);
    }

    // PUT /api/products/{id} - Update product
    @PutMapping("/{id}")
    public ResponseEntity<EntityModel<Product>> updateProduct(
            @PathVariable Long id, @RequestBody Product product) {

        return productService.findById(id)
            .map(existingProduct -> {
                product.setId(id);
                Product updatedProduct = productService.save(product);

                EntityModel<Product> productModel = EntityModel.of(updatedProduct,
                    linkTo(methodOn(ProductController.class).getProduct(id)).withSelfRel(),
                    linkTo(methodOn(ProductController.class).getAllProducts()).withRel("products")
                );

                return ResponseEntity.ok(productModel);
            })
            .orElse(ResponseEntity.notFound().build());
    }

    // DELETE /api/products/{id} - Delete product
    @DeleteMapping("/{id}")
    public ResponseEntity<Void> deleteProduct(@PathVariable Long id) {
        if (productService.existsById(id)) {
            productService.deleteById(id);
            return ResponseEntity.noContent().build();
        }
        return ResponseEntity.notFound().build();
    }
}

3. Python Flask REST API

from flask import Flask, jsonify, request, url_for
from werkzeug.exceptions import NotFound, BadRequest

app = Flask(__name__)

# In-memory database
products = [
    {'id': 1, 'name': 'Laptop', 'price': 999.99, 'category': 'Electronics'},
    {'id': 2, 'name': 'Mouse', 'price': 29.99, 'category': 'Electronics'}
]

def generate_links(product_id=None):
    """Generate HATEOAS links"""
    links = {
        'products': {'href': url_for('get_products', _external=True)}
    }

    if product_id:
        links.update({
            'self': {'href': url_for('get_product', id=product_id, _external=True)},
            'update': {'href': url_for('update_product', id=product_id, _external=True)},
            'delete': {'href': url_for('delete_product', id=product_id, _external=True)}
        })

    return links

@app.route('/api/products', methods=['GET'])
def get_products():
    """Retrieve all products"""
    return jsonify({
        'products': products,
        '_links': generate_links()
    }), 200

@app.route('/api/products/<int:product_id>', methods=['GET'])
def get_product(product_id):
    """Retrieve single product"""
    product = next((p for p in products if p['id'] == product_id), None)

    if not product:
        return jsonify({
            'error': 'Product not found',
            '_links': generate_links()
        }), 404

    return jsonify({
        'product': product,
        '_links': generate_links(product_id)
    }), 200

@app.route('/api/products', methods=['POST'])
def create_product():
    """Create new product"""
    data = request.get_json()

    if not data or 'name' not in data or 'price' not in data:
        return jsonify({
            'error': 'Name and price are required',
            '_links': generate_links()
        }), 400

    new_product = {
        'id': len(products) + 1,
        'name': data['name'],
        'price': data['price'],
        'category': data.get('category', 'Uncategorized')
    }

    products.append(new_product)

    return jsonify({
        'message': 'Product created successfully',
        'product': new_product,
        '_links': generate_links(new_product['id'])
    }), 201

@app.route('/api/products/<int:product_id>', methods=['PUT'])
def update_product(product_id):
    """Update product"""
    product = next((p for p in products if p['id'] == product_id), None)

    if not product:
        return jsonify({
            'error': 'Product not found',
            '_links': generate_links()
        }), 404

    data = request.get_json()

    if not data or 'name' not in data or 'price' not in data:
        return jsonify({
            'error': 'Name and price are required',
            '_links': generate_links(product_id)
        }), 400

    product.update({
        'name': data['name'],
        'price': data['price'],
        'category': data.get('category', product['category'])
    })

    return jsonify({
        'message': 'Product updated successfully',
        'product': product,
        '_links': generate_links(product_id)
    }), 200

@app.route('/api/products/<int:product_id>', methods=['DELETE'])
def delete_product(product_id):
    """Delete product"""
    global products
    product = next((p for p in products if p['id'] == product_id), None)

    if not product:
        return jsonify({
            'error': 'Product not found',
            '_links': generate_links()
        }), 404

    products = [p for p in products if p['id'] != product_id]

    return jsonify({
        'message': 'Product deleted successfully',
        '_links': generate_links()
    }), 200

if __name__ == '__main__':
    app.run(debug=True)

HTTP Status Codes

2xx Success

200 OK: Request successful
201 Created: Resource created
204 No Content: Request successful, no return

3xx Redirection

301 Moved Permanently: Permanent redirect
302 Found: Temporary redirect
304 Not Modified: Content unchanged (Cache)

4xx Client Errors

400 Bad Request: Invalid request
401 Unauthorized: Authentication required
403 Forbidden: Access denied
404 Not Found: Resource not found
409 Conflict: Conflict with existing state

5xx Server Errors

500 Internal Server Error: Server error
502 Bad Gateway: Gateway/proxy error
503 Service Unavailable: Service not available

Richardson Maturity Model

Level 0: Swamp of POX

POST /api/products
{"action": "getAll"}

Level 1: Resources

GET /api/getAllProducts
POST /api/createProduct

Level 2: HTTP Verbs

GET /api/products
POST /api/products
PUT /api/products/123
DELETE /api/products/123

Level 3: Hypermedia (HATEOAS)

{
  "product": {
    "id": 123,
    "name": "Laptop",
    "price": 999.99
  },
  "_links": {
    "self": { "href": "/api/products/123" },
    "update": { "href": "/api/products/123", "method": "PUT" },
    "delete": { "href": "/api/products/123", "method": "DELETE" },
    "products": { "href": "/api/products" }
  }
}

Advantages and Disadvantages

Advantages of REST

Scalability: Stateless architecture enables horizontal scaling
Flexibility: Various data formats (JSON, XML, HTML)
Simplicity: Uses established HTTP protocol
Cacheability: Responses can be cached
Separation: Clear separation of client and server

Disadvantages

Overhead: HTTP headers and JSON structure
Statelessness: Requires client-side state management
Versioning: API versioning can be complex
Security: HTTPS and authentication required

Common Exam Questions

What is the difference between PUT and PATCH? PUT replaces the entire resource, PATCH only modifies parts of the resource.
Explain HATEOAS! Hypermedia as the engine of application state - clients navigate through links without fixed URLs.
Why is statelessness important for REST? Enables horizontal scaling and simplifies load distribution.
What does idempotent mean for HTTP methods? Multiple executions lead to the same result (GET, PUT, DELETE).

REST API Fundamentals: HTTP Methods & Status Codes

REST API Fundamentals: HTTP Methods, Status Codes & HATEOAS

In a Nutshell

Compact Technical Description

Exam-Relevant Key Points

Core Components

Practical Examples

1. Resource Design and HTTP Methods

2. Spring Boot REST API with HATEOAS

3. Python Flask REST API

HTTP Status Codes

2xx Success

3xx Redirection

4xx Client Errors

5xx Server Errors

Richardson Maturity Model

Level 0: Swamp of POX

Level 1: Resources

Level 2: HTTP Verbs

Level 3: Hypermedia (HATEOAS)

Advantages and Disadvantages

Advantages of REST

Disadvantages

Common Exam Questions

Most Important Sources

Related Posts

REST API Fundamentals: HTTP Methods & Best Practices

REST Architecture Style Explained: Resources & APIs

Idempotency in HTTP & REST APIs Explained

REST API Fundamentals: HTTP Methods, Status Codes & HATEOAS

IRC-Mania Die Seite rund um Sicherheit und Programmierung

In a Nutshell

Compact Technical Description

Exam-Relevant Key Points

Core Components

Practical Examples

1. Resource Design and HTTP Methods

2. Spring Boot REST API with HATEOAS

3. Python Flask REST API

IRC-Security.de

HTTP Status Codes

2xx Success

3xx Redirection

4xx Client Errors

5xx Server Errors

Richardson Maturity Model

Level 0: Swamp of POX

Level 1: Resources

Level 2: HTTP Verbs

Level 3: Hypermedia (HATEOAS)

Advantages and Disadvantages

Advantages of REST

Disadvantages

Common Exam Questions

Most Important Sources

Premium VPS Hosting

Related Posts

REST API Fundamentals: HTTP Methods & Best Practices

REST Architecture Style Explained: Resources & APIs

Idempotency in HTTP & REST APIs Explained
