Number Systems: Binary, Hexadecimal, Decimal & Bit Operations

This article is a comprehensive introduction to number systems – including binary, hexadecimal, decimal, conversion, and bit operations with practical examples.

In a Nutshell

Computers use binary systems (0 and 1). Hexadecimal serves as a compact representation for binary values. Bit operations enable direct manipulation of data at the bit level.

Compact Technical Description

Number systems are methods for representing numbers with different bases. Computers internally use the binary system (base 2), while humans prefer the decimal system (base 10).

Important number systems:

Decimal System (Base 10)

• Digits: 0, 1, 2, 3, 4, 5, 6, 7, 8, 9
• Place values: 10⁰, 10¹, 10², 10³, …
• Usage: Human communication, everyday mathematics
• Example: 123 = 1×10² + 2×10¹ + 3×10⁰

Binary System (Base 2)

• Digits: 0, 1
• Place values: 2⁰, 2¹, 2², 2³, …
• Usage: Computer internal representation
• Example: 1011 = 1×2³ + 0×2² + 1×2¹ + 1×2⁰ = 11

Hexadecimal System (Base 16)

• Digits: 0-9, A, B, C, D, E, F
• Place values: 16⁰, 16¹, 16², 16³, …
• Usage: Compact binary representation, colors, memory addresses
• Example: A3 = 10×16¹ + 3×16⁰ = 163

Octal System (Base 8)

• Digits: 0, 1, 2, 3, 4, 5, 6, 7
• Place values: 8⁰, 8¹, 8², 8³, …
• Usage: Historical use in Unix systems
• Example: 75 = 7×8¹ + 5×8⁰ = 61

Exam-Relevant Key Points

• Decimal system: Base 10, digits 0-9, place values 10ⁿ
• Binary system: Base 2, digits 0-1, computer representation
• Hexadecimal system: Base 16, digits 0-9, A-F, compact representation
• Conversion: Division/multiplication with base, place value method
• Bit operations: AND, OR, XOR, NOT, shift operations
• Two’s complement: Negative numbers in binary system
• IHK-relevant: Foundation for computer architecture and programming

Core Components

1. Number systems: Decimal, binary, hexadecimal, octal
2. Conversion: Between different bases
3. Bit operations: AND, OR, XOR, NOT, shift
4. Two’s complement: Negative numbers
5. Computer arithmetic: Addition, subtraction, multiplication
6. Data types: Bits, bytes, words
7. Memory representation: Hexadecimal addresses
8. Error detection: Parity, checksums

Practical Examples

1. Conversion Between Number Systems

public class ZahlensystemUmrechnung {

    // Dezimal zu Binär
    public static String dezimalZuBinaer(int dezimal) {
        if (dezimal == 0) return "0";

        StringBuilder binaer = new StringBuilder();
        while (dezimal > 0) {
            binaer.append(dezimal % 2);
            dezimal /= 2;
        }
        return binaer.reverse().toString();
    }

    // Binär zu Dezimal
    public static int binaerZuDezimal(String binaer) {
        int dezimal = 0;
        int potenz = 0;

        for (int i = binaer.length() - 1; i >= 0; i--) {
            if (binaer.charAt(i) == '1') {
                dezimal += Math.pow(2, potenz);
            }
            potenz++;
        }
        return dezimal;
    }

    // Dezimal zu Hexadezimal
    public static String dezimalZuHex(int dezimal) {
        if (dezimal == 0) return "0";

        char[] hexZiffern = {'0', '1', '2', '3', '4', '5', '6', '7',
                           '8', '9', 'A', 'B', 'C', 'D', 'E', 'F'};
        StringBuilder hex = new StringBuilder();

        while (dezimal > 0) {
            int rest = dezimal % 16;
            hex.append(hexZiffern[rest]);
            dezimal /= 16;
        }
        return hex.reverse().toString();
    }

    // Hexadezimal zu Dezimal
    public static int hexZuDezimal(String hex) {
        int dezimal = 0;
        String hexZiffern = "0123456789ABCDEF";

        for (int i = 0; i < hex.length(); i++) {
            char ziffer = hex.charAt(i);
            int wert = hexZiffern.indexOf(ziffer);
            dezimal = dezimal * 16 + wert;
        }
        return dezimal;
    }

    // Binär zu Hexadezimal
    public static String binaerZuHex(String binaer) {
        // Binär in 4er-Gruppen aufteilen
        while (binaer.length() % 4 != 0) {
            binaer = "0" + binaer;
        }

        StringBuilder hex = new StringBuilder();
        for (int i = 0; i < binaer.length(); i += 4) {
            String nibble = binaer.substring(i, i + 4);
            int wert = binaerZuDezimal(nibble);
            hex.append(dezimalZuHex(wert));
        }
        return hex.toString();
    }

    // Hexadezimal zu Binär
    public static String hexZuBinaer(String hex) {
        String[] binaerMap = {
            "0000", "0001", "0010", "0011",
            "0100", "0101", "0110", "0111",
            "1000", "1001", "1010", "1011",
            "1100", "1101", "1110", "1111"
        };

        StringBuilder binaer = new StringBuilder();
        for (int i = 0; i < hex.length(); i++) {
            char ziffer = hex.charAt(i);
            int wert = "0123456789ABCDEF".indexOf(ziffer);
            binaer.append(binaerMap[wert]);
        }

        // Führende Nullen entfernen
        while (binaer.length() > 1 && binaer.charAt(0) == '0') {
            binaer.deleteCharAt(0);
        }

        return binaer.toString();
    }

    public static void main(String[] args) {
        int zahl = 175;

        System.out.println("Zahl: " + zahl);
        System.out.println("Binär: " + dezimalZuBinaer(zahl));
        System.out.println("Hex: " + dezimalZuHex(zahl));

        String binaer = "10101111";
        String hex = "AF";

        System.out.println("\nBinär " + binaer + " = Dezimal " + binaerZuDezimal(binaer));
        System.out.println("Hex " + hex + " = Dezimal " + hexZuDezimal(hex));
        System.out.println("Binär " + binaer + " = Hex " + binaerZuHex(binaer));
        System.out.println("Hex " + hex + " = Binär " + hexZuBinaer(hex));
    }
}

2. Bit Operations in Various Languages

// Java Bit Operations
public class BitOperationen {

    public static void main(String[] args) {
        int a = 12;  // 1100 in binary
        int b = 10;  // 1010 in binary

        System.out.println("a = " + a + " (Binary: " + Integer.toBinaryString(a) + ")");
        System.out.println("b = " + b + " (Binary: " + Integer.toBinaryString(b) + ")");

        // Bitwise AND (&)
        int and = a & b;  // 1100 & 1010 = 1000 (8)
        System.out.println("a & b = " + and + " (Binary: " + Integer.toBinaryString(and) + ")");

        // Bitwise OR (|)
        int or = a | b;   // 1100 | 1010 = 1110 (14)
        System.out.println("a | b = " + or + " (Binary: " + Integer.toBinaryString(or) + ")");

        // Bitwise XOR (^)
        int xor = a ^ b;  // 1100 ^ 1010 = 0110 (6)
        System.out.println("a ^ b = " + xor + " (Binary: " + Integer.toBinaryString(xor) + ")");

        // Bitwise NOT (~)
        int notA = ~a;   // ~1100 = 0011 (with two's complement)
        System.out.println("~a = " + notA + " (Binary: " + Integer.toBinaryString(notA) + ")");

        // Left Shift (<<)
        int leftShift = a << 2;  // 1100 << 2 = 110000 (48)
        System.out.println("a << 2 = " + leftShift + " (Binary: " + Integer.toBinaryString(leftShift) + ")");

        // Right Shift (>>)
        int rightShift = a >> 1;  // 1100 >> 1 = 0110 (6)
        System.out.println("a >> 1 = " + rightShift + " (Binary: " + Integer.toBinaryString(rightShift) + ")");

        // Unsigned Right Shift (>>>)
        int unsignedRightShift = a >>> 1;  // 1100 >>> 1 = 0110 (6)
        System.out.println("a >>> 1 = " + unsignedRightShift + " (Binary: " + Integer.toBinaryString(unsignedRightShift) + ")");

        // Practical applications
        praktischeAnwendungen();
    }

    private static void praktischeAnwendungen() {
        System.out.println("\n=== Practical Applications ===");

        // Check bit (is the 3rd bit set?)
        int zahl = 12;  // 1100
        int bitPosition = 2;
        boolean bitSet = (zahl & (1 << bitPosition)) != 0;
        System.out.println("Bit " + bitPosition + " in " + zahl + " set: " + bitSet);

        // Set bit
        int mitBit = zahl | (1 << bitPosition);
        System.out.println("Set bit " + bitPosition + ": " + mitBit);

        // Clear bit
        int ohneBit = zahl & ~(1 << bitPosition);
        System.out.println("Clear bit " + bitPosition + ": " + ohneBit);

        // Toggle bit
        int umgeschaltet = zahl ^ (1 << bitPosition);
        System.out.println("Toggle bit " + bitPosition + ": " + umgeschaltet);

        // Extract color from RGB values
        int farbe = 0xFF6B35;  // Orange
        int rot = (farbe >> 16) & 0xFF;
        int gruen = (farbe >> 8) & 0xFF;
        int blau = farbe & 0xFF;

        System.out.println("\nColor: #" + Integer.toHexString(farbe).toUpperCase());
        System.out.println("Red: " + rot);
        System.out.println("Green: " + gruen);
        System.out.println("Blue: " + blau);
    }
}

3. Two’s Complement for Negative Numbers

public class Zweierkomplement {

    // Zweierkomplement berechnen
    public static String zweierkomplement(int zahl, int bits) {
        if (zahl >= 0) {
            return String.format("%" + bits + "s", Integer.toBinaryString(zahl)).replace(' ', '0');
        }

        // Negative Zahl: 2^bits - |zahl|
        int positiv = (int) (Math.pow(2, bits) + zahl);
        return String.format("%" + bits + "s", Integer.toBinaryString(positiv)).replace(' ', '0');
    }

    // Aus Zweierkomplement Dezimalwert berechnen
    public static int vonZweierkomplement(String binaer) {
        int bits = binaer.length();

        // Wenn höchstes Bit 0 ist, positive Zahl
        if (binaer.charAt(0) == '0') {
            return Integer.parseInt(binaer, 2);
        }

        // Negative Zahl: - (2^bits - wert)
        int wert = Integer.parseInt(binaer, 2);
        return wert - (int) Math.pow(2, bits);
    }

    public static void main(String[] args) {
        int[] zahlen = {13, 5, 0, -1, -5, -13};
        int bits = 8;

        System.out.println("Two's complement with " + bits + " bits:");
        System.out.println("Number\tBinary\t\tDecimal");
        System.out.println("----\t----\t\t-------");

        for (int zahl : zahlen) {
            String binaer = zweierkomplement(zahl, bits);
            System.out.println(zahl + "\t" + binaer + "\t" + vonZweierkomplement(binaer));
        }

        // Bereichsanzeige
        System.out.println("\nRange with " + bits + " bits:");
        System.out.println("Minimum: " + (-(int) Math.pow(2, bits-1)));
        System.out.println("Maximum: " + ((int) Math.pow(2, bits-1) - 1));

        // Überlauf demonstrieren
        System.out.println("\nOverflow Demonstration:");
        int max = (int) Math.pow(2, bits-1) - 1;
        int ueberlauf = max + 1;

        System.out.println("Max: " + max + " -> " + zweierkomplement(max, bits));
        System.out.println("Max+1: " + ueberlauf + " -> " + zweierkomplement(ueberlauf, bits));
        System.out.println("Expected: " + (-(int) Math.pow(2, bits-1)) + " -> " + zweierkomplement(-(int) Math.pow(2, bits-1), bits));
    }
}

4. Computer Arithmetic

public class Computerarithmetik {

    // Binäre Addition
    public static String binaerAddition(String a, String b) {
        int laenge = Math.max(a.length(), b.length());

        // Mit führenden Nullen auffüllen
        a = String.format("%" + laenge + "s", a).replace(' ', '0');
        b = String.format("%" + laenge + "s", b).replace(' ', '0');

        StringBuilder ergebnis = new StringBuilder();
        int carry = 0;

        // Von rechts nach links addieren
        for (int i = laenge - 1; i >= 0; i--) {
            int summe = carry + (a.charAt(i) - '0') + (b.charAt(i) - '0');
            ergebnis.append(summe % 2);
            carry = summe / 2;
        }

        // Carry am Ende hinzufügen
        if (carry > 0) {
            ergebnis.append(carry);
        }

        return ergebnis.reverse().toString();
    }

    // Binäre Subtraktion (Zweierkomplement-Methode)
    public static String binaerSubtraktion(String a, String b) {
        // b negieren (Zweierkomplement)
        String negiert = zweierkomplementNegieren(b);

        // a + (-b)
        return binaerAddition(a, negiert);
    }

    private static String zweierkomplementNegieren(String binaer) {
        // Bits invertieren
        StringBuilder invertiert = new StringBuilder();
        for (char bit : binaer.toCharArray()) {
            invertiert.append(bit == '0' ? '1' : '0');
        }

        // 1 addieren
        return binaerAddition(invertiert.toString(), "1");
    }

    // Binäre Multiplikation
    public static String binaerMultiplikation(String a, String b) {
        int aDez = Integer.parseInt(a, 2);
        int bDez = Integer.parseInt(b, 2);
        int produkt = aDez * bDez;

        return Integer.toBinaryString(produkt);
    }

    // Feste-Punkt-Arithmetik
    public static double festePunktAddition(double a, double b, int nachkommastellen) {
        int faktor = (int) Math.pow(10, nachkommastellen);
        int aInt = (int) Math.round(a * faktor);
        int bInt = (int) Math.round(b * faktor);
        int ergebnisInt = aInt + bInt;

        return (double) ergebnisInt / faktor;
    }

    // Gleitkomma-Darstellung (vereinfacht)
    public static void gleitkommaDarstellung(double zahl) {
        if (zahl == 0) {
            System.out.println("0 = 0.0 × 2^0");
            return;
        }

        boolean negativ = zahl < 0;
        zahl = Math.abs(zahl);

        int exponent = 0;

        // Normalisieren
        while (zahl >= 2.0) {
            zahl /= 2.0;
            exponent++;
        }

        while (zahl < 1.0) {
            zahl *= 2.0;
            exponent--;
        }

        System.out.println((negativ ? "-" : "") + zahl + " × 2^" + exponent);
    }

    public static void main(String[] args) {
        System.out.println("=== Binary Arithmetic ===");

        String a = "1011";  // 11
        String b = "1101";  // 13

        System.out.println("a = " + a + " (" + Integer.parseInt(a, 2) + ")");
        System.out.println("b = " + b + " (" + Integer.parseInt(b, 2) + ")");

        String summe = binaerAddition(a, b);
        System.out.println("a + b = " + summe + " (" + Integer.parseInt(summe, 2) + ")");

        String differenz = binaerSubtraktion(b, a);
        System.out.println("b - a = " + differenz + " (" + Integer.parseInt(differenz, 2) + ")");

        String produkt = binaerMultiplikation(a, b);
        System.out.println("a × b = " + produkt + " (" + Integer.parseInt(produkt, 2) + ")");

        System.out.println("\n=== Fixed-Point Arithmetic ===");
        double x = 12.34;
        double y = 5.67;
        double summeFP = festePunktAddition(x, y, 2);
        System.out.println(x + " + " + y + " = " + summeFP + " (2 decimal places)");

        System.out.println("\n=== Floating-Point Representation ===");
        double[] zahlen = {12.5, 0.75, -3.125, 256.0};
        for (double zahl : zahlen) {
            System.out.print(zahl + " = ");
            gleitkommaDarstellung(zahl);
        }
    }
}

5. Python Bit Operations and Number Systems

# Python number systems and bit operations

def dezimal_zu_binaer(dezimal):
    """Convert decimal to binary"""
    if dezimal == 0:
        return "0"

    binaer = ""
    while dezimal > 0:
        binaer = str(dezimal % 2) + binaer
        dezimal //= 2

    return binaer

def binaer_zu_dezimal(binaer):
    """Convert binary to decimal"""
    return int(binaer, 2)

def dezimal_zu_hex(dezimal):
    """Convert decimal to hexadecimal"""
    hex_ziffern = "0123456789ABCDEF"

    if dezimal == 0:
        return "0"

    hex = ""
    while dezimal > 0:
        hex = hex_ziffern[dezimal % 16] + hex
        dezimal //= 16

    return hex

def hex_zu_dezimal(hex):
    """Convert hexadecimal to decimal"""
    return int(hex, 16)

def bit_operationen_demo():
    """Demonstrate bit operations"""
    a = 12  # 1100
    b = 10  # 1010

    print(f"a = {a} (Binary: {bin(a)})")
    print(f"b = {b} (Binary: {bin(b)})")

    # Bitwise AND
    and_result = a & b
    print(f"a & b = {and_result} (Binary: {bin(and_result)})")

    # Bitwise OR
    or_result = a | b
    print(f"a | b = {or_result} (Binary: {bin(or_result)})")

    # Bitwise XOR
    xor_result = a ^ b
    print(f"a ^ b = {xor_result} (Binary: {bin(xor_result)})")

    # Bitwise NOT
    not_a = ~a
    print(f"~a = {not_a} (Binary: {bin(not_a & 0xFFFFFFFF)})")

    # Left Shift
    left_shift = a << 2
    print(f"a << 2 = {left_shift} (Binary: {bin(left_shift)})")

    # Right Shift
    right_shift = a >> 1
    print(f"a >> 1 = {right_shift} (Binary: {bin(right_shift)})")

def farbe_aus_rgb(rot, gruen, blau):
    """Combine RGB color as 24-bit value"""
    return (rot << 16) | (gruen << 8) | blau

def rgb_aus_farbe(farbe):
    """Extract RGB components from 24-bit color"""
    rot = (farbe >> 16) & 0xFF
    gruen = (farbe >> 8) & 0xFF
    blau = farbe & 0xFF
    return rot, gruen, blau

def bit_manipulation_demo():
    """Demonstrate bit manipulation"""
    zahl = 0b10101000  # 168

    print(f"Original number: {zahl} (Binary: {bin(zahl)})")

    # Check bit
    bit_position = 3
    bit_gesetzt = (zahl & (1 << bit_position)) != 0
    print(f"Bit {bit_position} set: {bit_gesetzt}")

    # Set bit
    mit_bit = zahl | (1 << bit_position)
    print(f"Set bit {bit_position}: {mit_bit} (Binary: {bin(mit_bit)})")

    # Clear bit
    ohne_bit = zahl & ~(1 << bit_position)
    print(f"Clear bit {bit_position}: {ohne_bit} (Binary: {bin(ohne_bit)})")

    # Toggle bit
    umgeschaltet = zahl ^ (1 << bit_position)
    print(f"Toggle bit {bit_position}: {umgeschaltet} (Binary: {bin(umgeschaltet)})")

def hauptprogramm():
    """Main program with all demonstrations"""
    print("=== Number System Conversion ===")

    zahl = 175
    print(f"Decimal {zahl}:")
    print(f"  Binary: {dezimal_zu_binaer(zahl)}")
    print(f"  Hex: {dezimal_zu_hex(zahl)}")

    print("\n=== Bit Operations ===")
    bit_operationen_demo()

    print("\n=== Bit Manipulation ===")
    bit_manipulation_demo()

    print("\n=== Colors as RGB ===")
    orange = farbe_aus_rgb(255, 107, 53)
    print(f"Orange: #{orange:06X}")

    r, g, b = rgb_aus_farbe(orange)
    print(f"RGB: ({r}, {g}, {b})")

    print("\n=== Two's Complement (8-Bit) ===")
    for i in range(-5, 6):
        if i >= 0:
            binaer = format(i, '08b')
        else:
            binaer = format((256 + i), '08b')
        print(f"{i:3d}: {binaer}")

if __name__ == "__main__":
    hauptprogramm()

Conversion Table

Decimal	Binary	Hexadecimal	Octal
0	0000	0	0
1	0001	1	1
2	0010	2	2
3	0011	3	3
4	0100	4	4
5	0101	5	5
6	0110	6	6
7	0111	7	7
8	1000	8	10
9	1001	9	11
10	1010	A	12
11	1011	B	13
12	1100	C	14
13	1101	D	15
14	1110	E	16
15	1111	F	17

Bit Operations Overview

| Operator | Symbol | Description | Example |
|----------|--------|-------------|----------|
| AND | & | Bitwise AND | 5 & 3 = 1 |
| OR | \| | Bitwise OR | 5 \| 3 = 7 |
| XOR | ^ | Exclusive OR | 5 ^ 3 = 6 |
| NOT | ~ | Bitwise NOT | ~5 = -6 |
| Left Shift | << | Shift left | 5 << 2 = 20 |
| Right Shift | >> | Shift right | 5 >> 1 = 2 |
| Unsigned Right Shift | >>> | Unsigned right shift | 5 >>> 1 = 2 |

Storage Sizes

Unit	Bytes	Bits	Range (unsigned)
Byte	1	8	0 - 255
Word	2	16	0 - 65,535
DWord	4	32	0 - 4,294,967,295
QWord	8	64	0 - 18,446,744,073,709,551,615

Two’s Complement Range

Bits	Minimum	Maximum
8	-128	127
16	-32,768	32,767
32	-2,147,483,648	2,147,483,647
64	-9,223,372,036,854,775,808	9,223,372,036,854,775,807

Advantages and Disadvantages

Advantages of Binary System

• Simple: Only two states (0 and 1)
• Reliable: Easy to implement without errors
• Efficient: Optimal for electronic circuits
• Universal: Foundation of all digital systems

Advantages of Hexadecimal System

• Compact: 4 binary digits = 1 hexadecimal digit
• Readable: Shorter and clearer than binary
• Standard: Widely used in programming
• Practical: Ideal for addresses and colors

Disadvantages

• Abstraction: Not intuitive for humans
• Conversion: Requires mental arithmetic
• Error-prone: Easy to make mistakes in manual conversion

Common Exam Questions

1. **Convert 175 (decimal) to binary and hexadecimal!**
   175₁₀ = 10101111₂ = AF₁₆

2. **What is the result of 12 & 10 (bitwise AND)?**
   12₁₀ = 1100₂, 10₁₀ = 1010₂ → 1100 & 1010 = 1000₂ = 8₁₀

3. **Explain two's complement!**
   Method for representing negative numbers in the binary system through bit inversion and adding 1.

4. **What are hexadecimal numbers used for?**
   Compact representation of binary values, colors, memory addresses, error codes.

Most Important Sources

1. https://de.wikipedia.org/wiki/Zahlensystem
2. https://de.wikipedia.org/wiki/Zweierkomplement
3. https://docs.oracle.com/javase/tutorial/java/nutsandbolts/op3.html
